產品特點
適用於改善區域內的通訊品質，在較弱的收訊區或在眾多基地台的地方，藉由八木天線的高方向性，將來自側方、後方基地台訊號降低，使通訊效果更佳。
[:en]
Suitable for improving communication quality in weak signal areas or places with many base stations, by utilizing the high directional performance of the Yagi antenna to reduce signals from base stations coming from the side or rear, resulting in better communication effectiveness.
(1) Electrical Specification:
頻率範圍： 800~960MHz
增益： 8dBi
駐波比： 1.5:1(典型),1.7:1(最大値)
輻射性 Direction
極化方式： 垂直
水平波瓣寬度 68°
垂直波瓣寬度 95°
防雷保護 可另加Lightening Arrester
輸入最大功率 50W
阻抗 ：50Ώ
(2) Environmental& Mechanical:
接頭 N Female
產品材質： 中碳鋼烤白漆
安裝方式 ：室外金屬桿
支撐桿直徑 Ø30~Ø45mm
天線尺寸：28 x 19.2 x 3.8 CM
重量： 0.3 KG
固定物：U形夾+螺絲
抗風強度 100mPH
IP等級:IP62
工作溫度 -5℃ to+45℃
儲藏溫度 -15℃ to+50℃[:en](1) Electrical Specification:
Frequency Range: 800~960MHz
Gain: 8dBi VSWR: 1.5:1 (typical), 1.7:1 (maximum)
Radiation Pattern: Directional
Polarization: Vertical Horizontal
Beamwidth: 68°
Vertical Beamwidth: 95°
Lightning Protection: Can be added with a Lightening Arrester
Input Power: Maximum 50W
Impedance: 50Ώ
(2) Environmental & Mechanical:
Connector: N Female
Material: Medium Carbon Steel baked with white paint
Mounting Method: Outdoor metal pole
Supporting Pole Diameter: Ø30~Ø45mm
Antenna Size: 28 x 19.2 x 3.8 CM
Weight: 0.3 KG
Mounting Hardware: U-Clamp + Screws
Wind Load: 100mPH IP Rating: IP62
Operating Temperature: -5℃ to +45℃
Storage Temperature: -15℃ to +50℃
(1) Electrical Specification:
頻率範圍： 800~960MHz
增益： 8dBi
駐波比： 1.5:1(典型),1.7:1(最大値)
輻射性 Direction
極化方式： 垂直
水平波瓣寬度 68°
垂直波瓣寬度 95°
防雷保護 可另加Lightening Arrester
輸入最大功率 50W
阻抗 ：50Ώ
(2) Environmental& Mechanical:
接頭 N Female
產品材質： 中碳鋼烤白漆
安裝方式 ：室外金屬桿
支撐桿直徑 Ø30~Ø45mm
天線尺寸：28 x 19.2 x 3.8 CM
重量： 0.3 KG
固定物：U形夾+螺絲
抗風強度 100mPH
IP等級:IP62
工作溫度 -5℃ to+45℃
儲藏溫度 -15℃ to+50℃[:en](1) Electrical Specification:
Frequency Range: 800~960MHz
Gain: 8dBi VSWR: 1.5:1 (typical), 1.7:1 (maximum)
Radiation Pattern: Directional
Polarization: Vertical Horizontal
Beamwidth: 68°
Vertical Beamwidth: 95°
Lightning Protection: Can be added with a Lightening Arrester
Input Power: Maximum 50W
Impedance: 50Ώ
(2) Environmental & Mechanical:
Connector: N Female
Material: Medium Carbon Steel baked with white paint
Mounting Method: Outdoor metal pole
Supporting Pole Diameter: Ø30~Ø45mm
Antenna Size: 28 x 19.2 x 3.8 CM
Weight: 0.3 KG
Mounting Hardware: U-Clamp + Screws
Wind Load: 100mPH IP Rating: IP62
Operating Temperature: -5℃ to +45℃
Storage Temperature: -15℃ to +50℃
